PG3A – Centrifugal Dewatering Pump 3″ – Petrol

SKU 5000007659 Category

Remove clean water from your job site fast and economically with the PG 3 dewatering pump. This simple, easy to use pump is designed to move water up to 264 gpm (1000 L/min) with very little solids, up to 0.25-inch (6.5 mm). With its self-priming centrifugal pumping action and overall compact size, the pump is ideal for the contractor with the need for temporary water removal.

– Cast iron impeller and volute are wear resistant for long life and minimal service.

– Pump out vanes on back of impeller reduce debris accumulation and downtime while allowing greater productivity.

– Carbon ceramic mechanical seal teamed with reliable four-cycle engine with low oil shutdown provides for increased operating life.

– High strength lightweight die cast aluminum housing increases the years of trouble-free pump life. A heavy duty protective frame provides convenient carrying handles while adding extra protection for the pump.

Technical Specifications

Dimensions (L x W x H)514 x 404 x 462 mm
Diameter suction and discharge76.2 mm
Operating weight 29 kg
Discharge head 27 m
Discharge capacity1,097 L/min
Suction height lift7.6 m
Solids diameter max. size6.5 mm

Engine / Motor

Engine / Motor type Air Cooled Single Cylinder
Engine / Motor manufacturerHonda
Engine / Motor modelGX160W1C2
Displacement 163 cm³
Max engine speed3,600 rpm
Operating speed3,600 rpm
Power (max. rated)3.6 kW
Power rating specification SAE J1349
Engine oil capacity0.6 L
Fuel type Petrol
Fuel consumption 1.8 L/h
Fuel tank capacity3.6 L
Run time 2.1 hrs
